Brand: ASUS
Socket: AM5
RAM: 4
PCI-E: 1
M.2 Slots: 2
WIFI: Included
Ryzen 9000 desktop ready
Category | Details |
---|---|
Form Factor | Micro ATX |
CPU Socket | AM5 |
Chipset | AMD B650 |
Supported Processors | AMD Ryzen™ 7000, 8000, and 9000 Series Desktop Processors |
Memory Slots | 4 x DDR5 DIMM slots |
Memory Speed | Up to 6400 MHz (OC) |
Maximum Memory Capacity | 128GB |
Expansion Slots | 1 x PCIe 4.0 x16, 2 x PCIe 4.0 x1 |
Storage | 2 x M.2 slots (1 x PCIe 5.0 x4, 1 x PCIe 4.0 x4), 4 x SATA 6Gb/s ports |
Graphics Output | 2 x DisplayPort, 1 x HDMI |
Audio | Realtek 7.1-Channel High Definition Audio |
LAN | Realtek 2.5Gb Ethernet |
Wireless | Wi-Fi 6 |
USB Ports (Rear) | 2 x USB 3.2 Gen 2 (1 x Type-A, 1 x Type-C), 2 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0 Type-A |
USB Ports (Front) | 1 x USB 3.2 Gen 1 Type-C, 1 x USB 3.2 Gen 1 header (supports 2 ports), 2 x USB 2.0 headers (support 4 ports) |
Power Connectors | 1 x 24-pin Main Power connector, 1 x 8-pin +12V Power connector, 1 x 4-pin +12V Power connector |
Cooling Headers | 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 2 x 4-pin Chassis Fan headers |
RGB Headers | 3 x Addressable Gen 2 headers, 1 x Aura RGB header |
Special Features | Military-grade components, Enhanced power solution, Comprehensive cooling system |
